КВАД YAMAHA YFS200 БЛАСТЕР (88 - 06) - РУКОВОДСТВО

QUAD YAMAHA YFS200 BLASTER (88 - 06) - INSTRUKCJA

YAMAHA YFS200 BLASTER INSTRUKCJA NAPRAW CLYMER

Modele produkowane od 1988 do 2006 roku

Chcesz dowiedzieć się jak naprawić quad Yamaha YFS200 Blaster?

Odpowiedzią jest podręcznik Clymer.

Instrukcja napraw Clymer została stworzona specjalnie dla majsterkowiczów. Od podstawowej konserwacji, przez rozwiązywanie problemów, po całkowite odnowienie Twojego pojazdu, instrukcje Clymer zawierają wszystkie potrzebne informacje. To właśnie ta instrukcja może okazać się najważniejszym przyrządem w skrzynce z narzędziami, kup ją już dziś.

Modele opisane

• Yamaha YFS200 Blaster, 1988-2006

UWAGA!

Oferowana książka wydana jest w języku angielskim (niedostępna w polskiej wersji językowej).

This Yamaha Blaster ATV Manual is 424 pages.

QUICK REFERENCE DATA

CHAPTER ONE / GENERAL INFORMATION

Manual organization / Notes, warnings and cautions / Safety first / Service hints / Torque specifications / Fasteners / Lubricants / Sealant, cements and cleaners / Threadlocking compound / Expendable supplies / Serial numbers / Basic hand tools / Precision measuring tools / Test equipment / Special tools / Mechanic's tips / Ball bearing replacement / Seals /Specifications

CHAPTER TWO / TROUBLESHOOTING

Operating requirements / Starting the engine / Starting difficulties / Engine performance / Engine noises / Starting system / Charging system / Ignition system / Headlight troubleshooting / Taillight troubleshooting / Electrical troubleshooting / Fuel system / Engine overheating / 2-stroke leak down test / Clutch / Transmission / Kickstarter / Drive train noise / Oil level indicator system troubleshooting / Autolube oil injetion pump / Handling / Frame noise / Brakes

CHAPTER THREE / LUBRICATION, MAINTENANCE AND TUNE-UP

Service maintenance intervals schedule / Tune-up / Engine oil / Transmission oil / Air filter / Spark plug / Carburetor / Exhaust system / Autolube pump and engine oil lines / Crankcase ventilation hose inspection / Engine compression check / Ignition timing / Control cable lubrication / Throttle cable and speed limiter adjustment / Clutch cable adjustment / Brake inspection and adjustment / Drive chain / Tires, wheels and bearings / Steering and front suspension / Rear suspension / Frame / Nuts, bolts and other fasteners / Lighting equipment / Storage / Specifications

CHAPTER FOUR / ENGINE TOP END

Engine principles / Engine lubrication / Cleanliness / Exhaust system / Cylinder head / Cylinder / Piston, piston pin and piston rings / Reed valve assembly / Specifications

CHAPTER FIVE / ENGINE BOTTOM END

Servicing engine in frame / Engine / Drive sprocket / Countershaft seal replacement / Left side main bearing seal / Crankcase and crankshaft / Transmission shifting check / Engine break-in / Specifications

CHAPTER SIX / CLUTCH, KICKSTARTER AND EXTERNAL SHIFT MECHANISM

Right crankcase cover / Clutch service / Clutch push lever / Clutch cable replacement / Kickstarter / Idle gear / External shift mechanism / Primary drive gear and balancer gears / Specifications

CHAPTER SEVEN / TRANSMISSION AND INTERNAL SHIFT MECHANISM

Transmission operation / Transmission troubleshooting / Transmission / Transmission overhaul / Transmission inspection / Internal shift mechanism / Specifications

CHAPTER EIGHT / FUEL SYSTEM

Carburetor / Float adjustment / Carburetor rejetting / Fuel tank / Fuel shutoff valve / Air box / Throttle cable replacement / Throttle lever assembly / Specifications

CHAPTER NINE / ELECTRICAL SYSTEM

Component testing / Capacitor discharge ignition / Flywheel / CDI unit / Ignition coil / Throttle override system (T.O.R.S.) / Lighting system / Oil level indicator system / Lighting voltage tests / Voltage regulator / Switches / Wiring diagrams / Specifications

CHAPTER TEN / OIL INJECTION SYSTEM

System components / Oil pump bleeding / Autolube pump output test / Autolube pump / Oil hoses / Oil level indicator / Oil tank / Specifications

CHAPTER ELEVEN / FRONT SUSPENSION AND STEERING

Front wheel / Front brake drum/bearing assembly / Front suspension / Shock absorber / Steering knuckle / Control arms / Handlebar / Tie rods / Steering shaft / Tires and wheels / Specifications

CHAPTER TWELVE / REAR SUSPENSION

Rear wheels / Rear wheel hubs / Rear axle / Rear axle housing / Drive chain / Driven sprocket / Tire changing and tire repairs / Shock absorber / Rear swing arm / Specifications

CHAPTER THIRTEEN / BRAKES

Front drum brake / Front brake shoe replacement / Front brake shoes and brake panel / Rear brake caliper / Rear brake disc / Front brake cable replacement / Rear/parking brake cable replacement / Rear brake pedal / Specifications

CHAPTER FOURTEEN / BODY

Seat / Front cover / Fuel tank cover / Front guard / Front bumper / Front fender / Rear fender / Footpegs / Specifications

INDEX

WIRING DIAGRAMS

Yamaha YFS200 Blaster (1988 - 2006). Naprawa, przeglądy, budowa i konserwacja książka napisana w j.angielskim, Duża część opisu naprawy przedstawiona jest za pomocą fotografii quadu Yamaha YFS200 Blaster produkowanego w latach 1988 - 2006
