THINKSCAN SD2 THINKCAR Считыватель кодов ABS SRS

• 【ABS SRS System Scanner Diagnosis】THINKCAR SD2 OBD2 code reader provide Airbag System (SRS), Antilock Brake System (ABS) and Permanently update the Latest Version. The powerful scan tool quickly determines the cause of vehicle's failure, clears fault codes, and turns off Engine warning light. It also One-click generates complete Automotive Diagnostic Report to record the car information, review the former fault code and recorded data at any time. More and More private owners choose SD2 tools.
• 【Free 2 Reset Services From 28 Reset】ThinkScan SD2 Scanner Support 28 Reset such as Oil Reset, SAS Reset, TPMS,DPF,KEY IMMO,Break RESET etc.. 2 special Functions can be selected from 28 Reset,and Free Lifetime Update. Thinkcar SD2 offers comprehensive and swift diagnosis as an excellent Diagnostic scanner. SD2 scan Tool works on more than 60 vehicle brands over 10000 cars. Covers OBD2/EOBD/JOBD vehicles mostly manufactured after 1996.
• 【4 inch touch screen and Plug&Play mode】SD2 Code reader is equipped with large 4inch gorilla glass Touch Screen. Compared with other brand scan tools, Thinktool SD2 is more wear-resistant and scratch-resistant. Comes with 1GB ROM to ensure the software runs fast, and 16GB internal memory offers enough space to download more car modules and newest Reset. Plug and play mode makes SD2 auto connects with your car quickly and supports offline diagnosis for 98% 12v passenger car makes worldwide.
• 【Support 10 FULL OBDII Test Modes】THINKCAR SD2 car diagnostic tool supports all 10 test modes of OBDII test, including Identify VIN information, I/M Readiness status test, View freeze frame, View data stream, O2 Sensor, EVAP system test, On-Board monitor test, Read&Clear DTCs, DTC code look up, Turn off MIL(Malfunction Indicator Lights). This Code Scanner can handle most emission-related issues, Check Engine Light Failure, to help you prolong car lifespan with improved performance.
• 【Real-time Battery Voltage Display && AUTO VIN】When SD2 automotive tools properly connect with vehicle, the SD2 will display real-time battery voltage and get your VIN and vehicle info rapidly. It reads and cleans code, supports display data stream graphic, ScreenCap Function stores and playbacks dynamic data stream, helps you do quick analysis and diagnosis, solve the potential problem of the vehicle. Connect the car to use, No need to waste time to download the software First.

2022 NEW Version ThinkCar SD2 obd2 Code Reader (ABS SRS) Auto Diagnostic Scanner Tool with 28 Reset Function -- Lifetime Free Update

* Thinkscan SD2 is a new generation of Mid-to-High End DIY products based on Android system launched by THINKCAR, which can realize online upgrade of diagnostic software to enhance Powerful diagnosis features.This scan tool supports Full OBD2/EOBD Test Modes on

ABS(Anti-locking System)/ SRS(Airbag System)

, and the live data stream in a graph for these 2 systems is available. What’s more, it also features 28 Special Functions:

Oil Lamp Reset, SAS Calibration Reset, IMMO Reset, EPB Release Reset and Battery Match Reset etc.

. It is capable to help Automotive Enthusiast and Professional mechanics diagnose and maintain the vehicles more efficiently and profitably. It can perform a comprehensive diagnosis of all vehicle electronic control systems.

* Different series support different systems and functions.

*THINKCAR SD2 Code Reader Support 2 Systems (Permanent Free Update) :

1. ABS：Anti-lock Braking System

The diagnostic tool THINKCAR SD2 is available for accessing and performing diagnostics on Anti-lock Brake Systems respectively Whether it is the brake pad deviation, the brake pad does not return to position, or other reasons of failure. THINKCAR SD2 has the ability to retrieve ABS fault codes and tell you what the problem is through a visual inspection of all brake components, and then clear the codes. For the safety of your family, please pay attention to the health of the brake system in time.

2. SRS: Supplemental Restraint System

This OBD2 scanner THINKCAR SD2 supports Airbag System Diagnostic (SRS) for most domestic and imported vehicles. This scan tool can check the errors and clear the codes, view real-time live data to monitor the SRS running status, and solve security risks. Extend the service life of airbags and improve vehicle safety.

///OBD2 Scanner Basic Scan Function (Permanent Free Update) :

* Data Stream(Mode 1): This option retrieves and displays live data and parameters from the vehicle's ECU.

* I/M Readiness(Mode 1): An important part of a vehicle’s OBD II system is the Readiness Monitors, which are indicators used to find out if all of the emissions components have been evaluated by the OBD II system.

* Display Freeze Frame(Mode 2): When an emission-related fault occurs, certain vehicle conditions are recorded by the on-board computer.

* Read Codes(Mode 3): This option is used to identify which part of the Engine emission control system has malfunctioned.

* Clear Codes(Mode 4): After reading the retrieved codes from the vehicle and certain repairing, you can use this function to erase the codes from the vehicle. Before performing this function, please make sure the vehicle’s ignition key is in the ON position with the engine off.

* O2 Sensor test(Mode 5): The results of O2 sensor test are not live values but instead the results of the ECU’s last O2 sensor test. Not all test values are applicable to all vehicles, not all vehicles support the Oxygen Sensors screen.

* On-board monitor test(Mode 6): This function can be utilized to read the results of on-board diagnostic monitoring tests for specific components/systems.

* EVAP System Test(Mode 8): The EVAP test function lets you initiate a leak test for the vehicle’s EVAP system. The tool does not perform the leak test, but signals to vehicle's on-board computer to initiate the test. Before using the system test function, refer to the vehicle's service repair manual to determine the procedures necessary to stop the test.

* Vehicle Information(Mode 9): This option displays the vehicle information, such as VIN (Vehicle Identification Number), CID (Calibration ID) and CVN (Calibration Verification Number).

* Turn off MIL (Malfunction Indicator Lights)

/// Support 28 Kind of Special Functions (2 Free Optional from 28 Reset) :

1. Steering Angle (SAS) Reset: Help clear the steering angle memory and calibrate the steering angle sensor. Reset the steering angle to zero to keep the car running straight.

2. Oil Light Reset: Execute the engine oil life recalculation system after changing the oil.

3. TPMS Reset: Reset the tire pressure. Quickly look up the tire sensor IDs from the vehicle’s ECU, and perform TPMS replacement and Sensor Test.

4. ABS Bleeding : Help exhaust the air. Adjust the vehicle height sensor for level calibration. Compatible with Audi, Honda, GM, Ford and other 44 brands or models.

5. Injector Coding: Write the new injector code into the car system for correct cylinder injection quantity. The fuel injector receives the fuel injection pulse signal sent by the engine electronic control unit to precisely control the fuel injection volume.

6. IMMO Service: Disable any lost keys and add new keys. ***ONLY for cars with easy IMMO system.

7. DPF Regeneration: Specially works for Diesel Particulate Filter system with DPF regeneration, DPF component replacement teach-in and DPF teach-in after replacing the engine control unit.

8. GEAR Reset : Re-correct the communication of the gear position information output from the gearbox computer. When the vehicle has replaced the timing belt assembly, crankshaft position sensor, crankshaft flywheel, ECU learning is required.

9. Electric Throttle Relearn (Throttle Matching) : Initialize the throttle actuators to the default state. Leaking injectors and some dead injectors can be missed even when an injector is disabled. Other problems with the ignition system and mechanical components also may not show an rpm loss when an injector is turned off.

10. AdBlue Reset: Reset urea after the diesel exhaust treatment fluid is replaced or filled up.

11. CKP(Crank Position) Sensor Adaptive Learning (EGR Adaption): Learn the Exhaust Gas Recirculation valve after being cleaned. Monitors certain camshaft position sensors signals to determine if all conditions are met to continue with the procedure for Engine running.

12. Tire Reset: Set the size parameters of the modified or replaced tire.

13. AFS Headlamp Reset: Initialize the adaptive headlamp system.

14. Sunroof Initialization: Initialize the sunroof when locked off or closed.

15. Battery Reset (Battery Matching) : Evaluate the battery charge state, Monitor the close-circuit current, Register the battery after replacement, and Activate the rest state of the vehicle.

16. Brake (EPB) Reset : Help replace and reset the brake pad. Maintenance of electronic braking system's safety and efficiency.

17. Seat Calibration : Calibrate the memory in replaced or repaired seats.

18. Airbag Reset : Resets the airbag data to clear the airbag collision fault indicator.

19. A/F Reset : Set or learn Air/Fuel ratio parameters.

20. Gearbox (Transmission) Relearn Reset : Help complete the gearbox self-learning to improve gear shifting quality. Procedure Reset Transmission Adaptive Learning DIY. Start the car and drive. Once you perform this procedure the Engine Control Unit (ECU) and Transmission Control Unit (TCU) will work together to learn how you drive by monitoring your driving pattern.

21. Transport Mode : Deactivate the transport mode.

22. Windows Calibration : Perform door window matching to recover ECU initial memory.

23. Language Change : Change vehicle system language.

24. ODO Reset : Copy, write or rewrite the kilometer value.

25. NOx Sensor Reset : Reset catalytic converter learned value stored in ECU.

26. Stop/Start Reset : Set up the automatic start-stop function in ECU.

27. Coolant Bleeding : Activate the electronic water pump.

28. Suspension Reset (SUS Reset) : Adjust the vehicle body height sensor for level calibration.

*** Tips: The 2 special features cannot be changed once selected, so choose them carefully please. ***

Note: This special function DOES NOT apply to all car models.
