LUXMAN T-341L СТЕРЕО ТЮНЕР ЗОЛОТОЙ

Dane techniczne:

General

• Manufacturer: Luxman
• Model: T-341 L
• Year of manufacture: 1992 - 1993
• Color: Black or Champagne
• Remote control: via system bus, see special features
• Power consumption:
• Dimensions: 438 x 90 x 355 mm
• Weight: 4 kg

Luxman T-341 L/G: 550 DM

Connections

• Number of inputs: 2

  MW/LW antenna

  FM antenna

• Number of outputs: 1

  Output level: 800 mV

Technical Data

• Reception: FM/MW/LW
• Frequencies:

  FM: 87.50 - 108.00 Mhz

  MW: 522 kHz - 1620 kHz

LW: 153 kHz - 281 kHz

• Frequency response FM: 30 Hz - 15 kHz, ± 0.5 dB
• Usable sensitivity ( 98 MHz, mono ): 10.8 dBf
• Distortion factor: 0.1% (mono), 0.15% (stereo)

Signal-to-noise ratio: 78 dB (mono), 65 dB (stereo)

• Channel separation: 48 dB
• Selectivity: 62 dB
• Co-wave selection:
• Spurious wave selection: 80 dB
• Image frequency attenuation: 90 dB
• IF attenuation: 80 dB
• AM suppression:
• Muting threshold: 26 dBf
• Station memory: yes (20)

Special Features

• Timer
• Clock
• System bus - controllable via remote control of the amplifier (e.g. Luxman A-357, A-377, C-383, etc.)
