Универсальный инверторный трансформатор 3000 Вт 12/24 В

The equipment is available in 12/24v/48-60v/60-72v models! The default shipment is 12/24V. If you need other models, please leave a note!

Fan cooling and temperature control, high-speed cooling fan, safety protection equipment.

Buzzing alarm device: when the inverter is used, the inverter will send out a trickle alarm when the power supply battery is insufficient or the voltage is insufficient.

1. The inverter voltage must be consistent with the battery power supply voltage. For example, if the inverter voltage is 12V, your battery voltage must also be 12V, otherwise the inverter will not work or be damaged.

2. Be careful not to connect the positive and negative poles reversely, otherwise the inverter will burn out the fuse and smoke.

3. The power supply from the automobile cigarette lighter can only carry a load below 200W, otherwise the automobile fuse will be burnt.

4. The inverter is a temporary emergency product, which can help you eliminate the trouble caused by power failure. It is not a quiet product. In order to achieve the cooling effect, the fan will make noise. Please understand.

5. The machine shall be protected from dampness, heavy falling and sediment intrusion, and shall be protected from infants and young children from playing and being damaged.

Housing material: aluminum alloy

Input voltage: DC12V/24V, 48/60V, 60/72V

Output voltage: AC220V or 110V

Peak power: 6000W

Continuous output power: 3000W

Output frequency: 50 or 60Hz

USB： DC 5V/2A

Overload protection: with

Short circuit protection: with

Over temperature protection: with

Low voltage protection: 12V: 9.5V~10.5V 24V: 19.5V~20.5V

Overvoltage protection: 12V: 15V-16V 24V: 28.5V~29.5V

Ambient temperature (° C): - 5~45

Product net weight (g): 4.5Kg

Product size (mm): 425 * 170 * 100mm
